CI-601A & CI-605A
(0 Customer reviews)Açıklama
| Model Name | CI-601A | CI-605A | |
| Load cell applied voltage | DC 5V | ||
| No. of load cell connection | 10 (350ohm) | ||
| Load cell input range | -2.0mV/V ~ 3.0mV/V | ||
| Input Sensitivity | 0.5uV/D (certification), 0.3uV/D (non-certification) | ||
| A/D Internal Degradability | 1/520,000 | ||
| A/D External Degradability | 1/10,000(OIML/NTEP/KS), 1/20,000(Non approval) | ||
| A/D Conversion Speed | 200 time/sec | ||
| A/D Conversion Method | Sigma Delta | ||
| Display Type | 4.3″ TFT Color LCD | ||
| Key Specification | 10 number keys, 9 function keys | ||
| Communication | Basic | RS-232(COM1, COM2) | |
| Option | RS422, RS485, Analog_out/BCD_out | ||
| External in/output | – | Input 4/Output 6 | |
| Power used | AC | AC 100~240V, 50/60Hz | |
| Temperature used | -10℃ ~ 40℃ | ||
| Certification Specification | OIML, CE | ||
| Product Dimension (W x D x H/mm) | 192.9 x 190.2 x 98.4 | ||
| Product Weight (kg) | 1.5 | ||
